784Double Turret
External Threads Termimal Diameter .093
Specification
- Part number
- 784
- Type
- Double Turret
- Category
- Insulated Terminals Molded Diallyl
- Detail
- External Threads Termimal Diameter .093
Plating options and thickness are listed on the plating specifications page. Custom lengths, threads and platings are available — Staffall manufactures to print.
