1620Single Turret
External Threads
Specification
- Part number
- 1620
- Type
- Single Turret
- Category
- Insulated Terminals Molded Diallyl
- Detail
- External Threads
Plating options and thickness are listed on the plating specifications page. Custom lengths, threads and platings are available — Staffall manufactures to print.
